Prismatic Cell - LFP
Tianneng prismatic cell, use LFP material system, which has higher energy density, longer cycle life and higher safety. It is the most advanced lithium battery with fully automated production and manufacturing process, ensuring excellent compatibility and adaptability to various application fields. Excellent quality, excellent user reputation, very suitable for energy storage, commercial vehicles, ships, industrial vehicles., etc.
Product Feature
The quality of Tianneng battery is good, and its excellent performance is shown here.
high quality
Prismatic battery, with good safety performance and strong adaptability.High cost performance, high competitiveness and high quality
Longer cycle life
The product cycle life is longer, reaching 6000 times @100% DOD
Wide operating temperature range
excellent high and low-temperature discharge performance, -20℃ discharge capacity ratio 80%, 55℃ discharge capacity ratio 108%
High energy density
High energy density is about 165wh/kg，the maximum continuous discharge is 1C， and the product has good compatibility.
Application Scenario
The application of this series of batteries in these products
All model parameters table
Selling different types of batteries, global dealers are welcome to buy our products.
| Model | Nominal Voltage (V) | Nominal Capacity (Ah) | Operating Voltage Range (V) | Dimension (mm±0.5) | Max continuous Discharging Current (A) |
|---|---|---|---|---|---|
| TLFPR50160119-100 | 3.2V | 100 | 2.50~3.65 | 50X160X116 | 1C |
| TLFPR79148120-150 | 3.2V | 150 | 2.50~3.65 | 79X148.5X116 .5 | 1C |
| TLFPR71173207-280 | 3.2V | 280 | 2.50~3.65 | 71X173.8X204.9 | 1C |
