Pouch Cell - LFP
Using LFP cell technology, Using the technology of LFP cells, the pouch lithium-ion battery cells have good cycle life, more than 2000 cycles, excellent high and low temperature discharge performance and stable performance.
Product Feature
The quality of Tianneng battery is good, and its excellent performance is shown here.
Longer service life
More than 2000 cycle life @ 100%DOD，using the technology of LFP cells
Wide operating temperature range
Charging: 0~45°C, discharging: -20~60°C ，Storage: -10~45℃
Stable performance
specific energy density is up to162 Wh/kg，automatic production process, high quality
Low self-discharge
self-discharge blow 4%, 100%SOC, under room temperature one month
Application Scenario
The application of this series of batteries in these products
All model parameters table
Selling different types of batteries, global dealers are welcome to buy our products.
| Model | Nominal Voltage (V) | Nominal Capacity (Ah) | Operating Voltage Range (V) | Dimension (mm) | Max continuous Discharging Current (A) |
|---|---|---|---|---|---|
| TLFPO11146300-50 | 3.2V | 50 | 2.50~3.65 | 11.2x146x300 | 3C |
| TLFPO13161230-50 | 3.2V | 50 | 2.50~3.65 | 13.0x161x232 | 3C |
