Cylindrical Cell - NCM
The cylindrical battery produced by Tianneng using NCM technology has the advantages of high energy density, long cycle life, outstanding high and low temperature performance, strong consistency, excellent product quality and excellent user reputation, so it is very suitable for low power products such as electric two-wheel / tricycle.
Product Feature
The quality of Tianneng battery is good, and its excellent performance is shown here.
1500 times @100% DOD
Cylindrical battery, with good safety performance and strong adaptability，The product cycle life is longer, reaching 1500 times @100% DOD
- 20 ℃——55℃
Excellent high and low temperature performance.，The capacity can be more than 70% at - 20 ℃, and more than 95% at 55 ℃
Superior safety
High energy density is about 200wh/kg，well uniformity of cylindrical lithium-ion battery cells。Passing a variety of safety testing, such as over-charge, over-discharge, short circuit, and over-temperature,etc ，Automated production process, well uniformity of cylindrical lithium-ion battery cells。
self-discharge blow 4%
Low self-discharge, self-discharge blow 4%, 100%SOC, under room temperature one month
Application Scenario
The application of this series of batteries in these products
All model parameters table
Sales of various types of batteries, global dealers are welcome to buy our products.
| Model | Nominal Voltage (V) | Nominal Capacity (Ah) | Operating Voltage Range (V) | Max continuous Discharging Current （A） | Material |
|---|---|---|---|---|---|
| TLNC18650-2000P | 3.6V | 2.1 | 2.75~4.20 | 3C | NCM |
| TLNC18650-2600P | 3.6V | 2.55 | 2.75~4.20 | 3C | NCM |
TLNC18650-2600R （Low resistance） | 3.6V | 2.55 | 2.75~4.20 | 3C | NCM |
| TLMFC26700-4000P | 3.7V | 4.0 | 2.75~4.20 | 2C | NCM+LMO |
| TLMFC26700-4800P | 3.7V | 4.8 | 2.75~4.20 | 2C | NCM+LMO |
