Cylindrical Cell - LFP
Tianneng uses LFP technology to produce cylindrical batteries with high energy density, long cycle life, outstanding high and low temperature performance and strong consistency.
Excellent product quality, excellent user reputation, very suitable for electric two-wheel / tricycle, golf cart, forklift and other low-power products.
Product Feature
The quality of Tianneng battery is good, and its excellent performance is shown here.
Cycle Life:
1500 times@100%DOD,0.5C/1C,25℃
Energy Density:
up to 140Wh/kg.
Self-discharge Rate:
≤4%, 100%SOC under room，temperature one month.
Operating Temperature:
Charging: 0~45°C，Discharging: -20~60°C，Storage: -10~45℃.
Application Scenario
The application of this series of batteries in these products
All model parameters table
Selling different types of batteries, global dealers are welcome to buy our products.
| Model | Nominal Voltage (V) | Nominal Capacity (Ah) | Operating Voltage Range (V) | Max continuous Discharging Current （A） | Material |
|---|---|---|---|---|---|
| TLFC26700-4000P | 3.2V | 4.0 | 2.00~3.65 | 2C | LFP |
| TLFC26700-4500P | 3.2V | 4.5 | 2.00~3.65 | 2C | LFP |
| TLFC32700-6000 | 3.2V | 6.0 | 2.00~3.65 | 3C | LFP |
